Drive Axle for Forklifts

Drive Axle for Forklift - The piece of machinery which is elastically connected to the framework of the vehicle utilizing a lift mast is called the forklift drive axle. The lift mast attaches to the drive axle and can be inclined, by at least one tilting cylinder, around the axial centerline of the drive axle. Frontward bearing parts along with back bearing parts of a torque bearing system are responsible for fastening the drive axle to the vehicle frame. The drive axle could be pivoted round a swiveling axis oriented horizontally and transversely in the vicinity of the rear bearing elements. The lift mast is likewise capable of being inclined relative to the drive axle. The tilting cylinder is connected to the lift truck frame and the lift mast in an articulated fashion. This enables the tilting cylinder to be oriented almost parallel to a plane extending from the axial centerline and to the swiveling axis.

Model H45, H35 and H40 forklifts, which are manufactured by Linde AG in Aschaffenburg, Germany, have a mounted lift mast tilt on the vehicle frame itself. The drive axle is elastically affixed to the frame of the lift truck by many different bearings. The drive axle has tubular axle body together with extension arms connected to it and extend rearwards. This type of drive axle is elastically affixed to the vehicle framework utilizing rear bearing parts on the extension arms together with forward bearing tools situated on the axle body. There are two rear and two front bearing devices. Each one is separated in the transverse direction of the vehicle from the other bearing device in its respective pair.

The drive and braking torques of the drive axle are sustained through the rear bearing components on the framework by the extension arms. The lift mast and the load generate the forces that are transmitted into the road or floor by the frame of the vehicle through the drive axle's front bearing parts. It is vital to make certain the parts of the drive axle are put together in a rigid enough method so as to maintain immovability of the forklift truck. The bearing elements could reduce minor bumps or road surface irregularities through travel to a limited extent and give a bit smoother operation.
